คุณสมบัติ | รายละเอียด |
|---|---|
| Series | TDR |
| Type | Switched Mode |
| Electrical Phase | 3 |
| AC or DC Input Voltage | ac, dc |
| Number of Outputs | 1 |
| Input Voltage | 340 → 550 V ac / 480 → 780V dc |
| AC or DC Output Voltage | dc |
| Output Voltage | 24V dc |
| Output Current | 10A |
| Power Rating | 240W |
| Dimensions | 63 x 113.5 x 125.2mm |
| Depth | 114mm |
| Width | 63mm |
| Height | 125mm |
| Maximum Temperature | +70°C |
| Standards Met | CE Certified, EN 61558, EN61000-3-2, EN61000-3-3, EN61000-4-11, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61204-3, UL Listed |
| Mounting Type | DIN Rail Mount |
| Special Features | 3 Year Warranty, 63 mm Slim Width, Cooling by Free Air Convection |
| MTBF | 515.4kh |
| Ripple And Noise | 100mV Pk-Pk |
| Efficiency | 92% |
| Minimum Temperature | -30°C |
| Output Voltage Adjustment Range | 24 → 28V |
| Load Regulation | ±1% |
