คุณสมบัติ | รายละเอียด |
|---|---|
| Supply Voltage | 24 → 240V ac/dc |
| Mounting Type | DIN Rail |
| Mode of Operation | Interval Delay, Interval Delay with Control Signal Off, Interval Delay with Control Signal Off and with Pause/Summation Control, Interval Delay with Pause/Summation Control Signal, Interval Delay with Retrigger/Restart Control Signal, OFF Delay with Control Signal, OFF Delay with Control Signal and with Pause/Summation, ON Delay and OFF Delay with Control Signal, Power ON Delay, Power ON Delay with Pause/Summation Control Signal, Power ON Delay with Retrigger/Restart Control, Symmetrical, Symmetrical with Pause/Summation Control Signal, Symmetrical with Retrigger/Restart Control Signal |
| Time Range | 0.05 → 1 s, 0.3 → 3 s, 1 → 10 s, 10 → 100 s, 3 → 30 h, 3 → 30 min, 3 → 30 s, 30 → 300 h, 30 → 300 min, 30 → 300s |
| Number of Contacts | 1 |
| Number of Timer Functions | Multi Function |
| Contact Configuration | SPDT |
| Time Increment | Hours, Minutes, Seconds |
| Maximum Current | 8A |
| Maximum Voltage | 240V ac/dc |
| Terminal Type | Screw |
| Switch Configuration | SPCO |
| Minimum Voltage | 24V ac/dc |
| Width | 90mm |
| Power Supply | External |
| Depth | 79.5mm |
| Minimum Current | 10mA |
| Maximum Operating Temperature | +60°C |
| Series | Harmony Time |
| Better World Verification | Green Premium |
| Better World Product | Yes |
| Length | 22.9mm |
| Time Delay | <100ms |
| Minimum Operating Temperature | -20°C |
1SVR730010R3200 CT-MBS.22S
BC7932N.81 AC/DC24V + AC230V 0.5-10S
2BDE20SLP24VDC
